BCE0726

High Performance Fanless Embedded System


Fanless Embedded Box PC BCE0726 Fanless Embedded Box PC BCE0726 Fanless Embedded Box PC BCE0726 Fanless Embedded Box PC BCE0726 Fanless Embedded Box PC BCE0726 Fanless Embedded Box PC BCE0726
  • Intel Core i7-8550U
  • Support 1 x SO-DIMM DDR4-2400Hz, up to 16GB
  • Support 2 x COM (RS232)
  • Support 1 x SATSIII (6.0Gb/s) Connector
  • Support 1 x M.2 2280 Slot
  • Support 2 x Intel i211-AT Gigabit LAN
  • Support Windows 10, Linux OS

Applications:

Amusement and Entertainment Device, KIOSK, Self-service Terminal, Interactive Digital Signage, Gambling Machine, E-desk, etc.

Main System
CPUIntel Core i7-8550U/ 18W 1.8GHz Quad Core
Intel Core i5-8250U/ 15W 1.6GHz Quad Core (optional)
BIOSAMI 64M DPI Flash ROM
RAM4GB SO-DIMM DDR4-2400 MHz; DDR4-2133 (optional)
Storage64GB SSD; SATA III (6.0Gb/s) or M.2 2880 Slot (optional)
Ethernet2 x Intel i211-AT Gigabit LAN
WiFi / 3G / 4G Module (optional)
Expansion1 x Mini-PCle
1 x SIM Card Slot
Rear I/O1 x DP
1 x HDMI
1 x Line-Out + MIC (2 In 1)
2 x USB 2.0
2 x Rj-45 (10 / 100 / 1000)
1 x DC 12V Power Input
2 x Antenna Holes
Front I/O1 x Power Button
1 x SIM Card Slot
2 x COM (RS232), COM2 Support RS232/485 (Optional)
4 x USB 3.0
Watchdog TimerOutput & Interval; Support Hardware Reset (256 level , 0~255 sec)
SystemWindows 7 /8 /10, Linux OS (optional)
Environment
PowerDC 12V/ 60W AC Adaptor
Operating Temperature-0°C ~ 50°C
Storage Temperature-10°C ~ 85°C
Dimensions186mm(W) x 126.5mm(D) x 66mm(H)
WeightTBD
Warranty2 year
