5.2” Commercial Grade Android Mobile Tablet PC

Commercial Grade Android Mobile Tablet PC Commercial Grade Android Mobile Tablet PC Commercial Grade Android Mobile Tablet PC Commercial Grade Android Mobile Tablet PC Commercial Grade Android Mobile Tablet PC
  • 5.2" Android 11.0 System with GMS

  • MTK MT6737 Octa Core

  • 5000mAh Capacity, Li-ion Battery

  • 2G, 3G, 4G LTE

  • IP65, 1.8m Drop Test

  • Support Fingerprint, UHF RFID Module


Logistics Management, Warehouse Optimization, Inventory Checking, Asset Management, Process Supervision

Other MCA Series == Back to MTP

MCA0522 5.2” Multiple Functions Tablet
Android 11.0, MT6763

5000mAh Large Capacity Battery
You don’t have to worry your business would be interrupted by power off anymore

Full Range of Data Collection Functions
Camera/ NFC/ 2D Barcode Scanner/ UHF RFID/ HF RFID/ PSAM/ Fingerprint/ Iris
Ticket Validation

Mobile Ordering

Inventory Management

Ticket Validation

Digital Signature

Multiple Modules Can Be Adapted To Virtually Any Job And Environment

Display type5.2" IPS
Resolution1920 x 1080
Brightness520 nits
Touch Panel5 Points Projected Capacitive Touch Panel
Main System
CPUMTK MT6737 Octa Core
OS SupportAndroid 11
Developing EnvironmentSDK: Supported
Language: Java
Tool: Eclipse / Android Studio
CommunicationWLAN: 802.11 a/b/g/n/ac (2.4G + 5G dual-band WiFi)
Bluetooth: 5.0
GNSS: GPS/AGPS, GLONASS, BeiDou; Internal Antenna
Card Slot1 x Nano SIM Card, 1 x Nano SIM or TF Card
InterfaceUSB 2.0 Type-C, OTG, Type-C Headphones Supported
Speaker1 x Speaker
Microphone2 x Microphone
SensorGravity sensor, Light sensor, Proximity sensor, Vibration motor
CameraFront: 5MP (Optional)
Rear: 13MP Camera with LED Light
ModuleNFC Module
Bardcode Scanner
Capacitive / Optical Fingerprint Module (Optional)
Internal UHF RFID Module (Optional)
Battery5000mAh Capacity, Li-ion Battery
Using TimeOver 12hrs (Depending on User Behavior / Environment)
Power InputAC 100 - 240V
Power AdapterDC 5V/2A
Keypad1 power key, 2 scan keys, 4 front keys, 1 user-defined key
Packing List
Standard Accessory 1 x Power Adapter (5V/2A)
1 x USB Type-C Cable
1 x Charging Cradle
1 x Docking Station
Product Dimension 164.2 x 78.8 x 17 mm
Product Weight 288g
Box Dimension 197 x 112 x 77 mm
Box Weight 630g
Rugged Feature IP65, 1.8m Drop Test
Operating Temperature -20°C to 50°C
Storage Temperature -40°C to 70°C
Humidity 5% ~ 95% (non-condensing)

Module Configuration

Bardcode Scanner
1D Barcode EngineZebra: SE965; Honeywell: N4313
2D Barcode EngineZebra: SE4710 / SE4750SR / SE4750MR / SE4750DP;
1D SymbologiesHoneywell: N6603 UPC/EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS, etc.
2D SymbologiesPDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode; Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal (KIX), etc.
NFC Module
Frequency13.56 MHz
ProtocolISO14443A/B, ISO15693, NFC-IP1, NFC-IP2, etc.
ChipsM1 card (S50, S70), CPU card, NFC tags, etc.
Range2 to 4 cm
Fingerprint Module
SensorTCS1/TCS2 Capacitive
Sensing Area (mm)12.8 x 18.0 ; 10.4 x 14.4
Resolution (dpi)508 dpi, 8-bit greylevel
CertificationsFIPS 201, STQC
Format ExtractionISO 19794, WSQ, ANSI 378, JPEG2000
Fake Finger DetectionSupport by SDK
SecurityAES, DES key encryption of the host communication channel
UHF RFID (Internal)
EngineImpinj E710 ; Impinj Indy R2000
Frequency865-868 MHz / 920-925 MHz / 902-928 MHz
ProtocolEPC C1 GEN2 / ISO18000-6C
AntennaCircular Polarized Antenna (4 dBi)
Power1W (30 dBm, +5 dBm to +30 dBm adjustable) ; 2W (33 dBm, for Latin America, etc.) (Optional)
R/W rangeUp to 15 m (open outdoors, Impinj MR6 tag)
Fastest Read Rate900+ tags/sec
Communication ModePin Connector

Optional Module

Standard Accessory

Power Adapter

USB Type-C Cable

Docking Station
